Visual Tools

Integrated visual debug system for rapid development — the "X-ray" that shows how everything works internally.

---

Debug System offers complete visibility into what happens during rendering:

🔧 What It Shows:

Information	Where It Appears	When It Updates	Useful For
Form State	Debug Panel	On every change	See values in real-time
Schema Applied	Schema Inspector	When schema changes	Validate structure
Component Resolution	Component Tree	On every render	Debug registry conflicts
Middleware Pipeline	Pipeline Tracer	Per execution	Performance tuning
Performance Metrics	Performance Monitor	Continuously	Optimization

📊 Automatic Activation:

Development Mode:

NODE_ENV=development → Debug Panel active automatically

Manual Override:

REACT_APP_DEBUG_schepta=true → Force debug in production

Runtime Toggle:

window.schepta_DEBUG = true; // Activate debug via console

💡 Result: Complete system transparency. Visual debug without configuration!

---

🚀 Debug System Components

Each tool has a specific function:

📊 Debug Panel - Main Panel:

Section	Content	Update	Interaction
Form Values	Current field values	Real-time	Read-only view
Validation State	Errors, touched, dirty	On validation	Click to see details
Schema Tree	Schema structure	On schema change	Expandable tree
Component Map	Resolved components	On render	Click to inspect
Performance	Render timing	Continuous	Hover for details

🔍 Schema Inspector - Schema Analysis:

Feature	Visualization	Purpose	Navigation
Schema Tree	Hierarchical view	See complete structure	Expand/collapse
Property Details	Key-value pairs	See properties	Click for details
Validation Rules	Rule list	See applied rules	Hover for description
Component Mapping	Schema → Component	See resolution	Click for component

🎛️ Component Tree - Hierarchy Viewer:

Information	Display	Purpose	Actions
Component Name	Tree node	Identify component type	Click to inspect
Props	Expandable object	See current props	Edit in devtools
Registry Source	Badge	See where component came from	Trace resolution
Render Count	Counter	Performance monitoring	Reset counter

⚡ Performance Monitor - Real-Time Metrics:

Metric	Measurement	Threshold	Alert
Render Time	Milliseconds per render	> 16ms	Performance warning
Re-render Count	Count per interaction	> 5	Optimization needed
Schema Processing	Time to process schema	> 50ms	Complex schema warning
Memory Usage	Component memory	> 10MB	Memory leak warning

---

⚙️ Debug Architecture

How the debug system works internally:

📋 Debug Pipeline:

Stage	Process	Data Collected	Storage
1. Hook Installation	Install debug hooks	Component lifecycle	Debug context
2. Data Collection	Collect render data	Props, state, timing	Circular buffer
3. Processing	Process collected data	Metrics, relationships	Computed state
4. Visualization	Update debug UI	Current snapshot	React/Vue state
5. Interaction	Handle user interaction	User selections	Local state

🎯 Data Collection Strategy:

Render Tracking:

const debugData = {
  timestamp: Date.now(),
  component: componentName,
  props: cloneDeep(props),
  schema: cloneDeep(schema),
  renderTime: performance.now() - startTime,
  memoryUsage: getMemoryUsage()
};

Pipeline Tracking:

const pipelineTrace = {
  middlewareName: middleware.name,
  inputProps: cloneDeep(inputProps),
  outputProps: cloneDeep(outputProps),
  executionTime: executionEnd - executionStart,
  errors: capturedErrors
};

Performance Tracking:

const performanceMetrics = {
  renderCount: renderCount,
  totalRenderTime: totalTime,
  averageRenderTime: totalTime / renderCount,
  memoryDelta: currentMemory - previousMemory
};

---

📊 Debug Features

Specific functionalities for each type of problem:

🔧 Form Debug Features:

Feature	Purpose	Data Shown	Actions Available
Value Inspector	See current values	Real-time form state	Copy values
Validation Tracer	Debug validation	Rules + results	Test validation
Field Mapper	Schema to component	Field mapping	Inspect component
Submit Tracer	Debug form submission	Submit data flow	Simulate submit

🧭 Menu Debug Features:

Feature	Purpose	Data Shown	Actions Available
Navigation Tree	Menu structure	Hierarchical menu	Expand/collapse
Visibility Logic	Debug show/hide	Visibility expressions	Test conditions
Route Mapping	Menu to routes	URL mappings	Navigate directly
Permission Check	Debug permissions	Permission logic	Test with roles

🎨 Component Debug Features:

Feature	Purpose	Data Shown	Actions Available
Registry Inspector	Debug component resolution	Resolution chain	Override components
Props Tracer	Debug props flow	Middleware pipeline	Test transformations
Context Viewer	Debug context	Context values	Modify context
Render Profiler	Debug performance	Render metrics	Profile renders

---

💡 Related Concepts

Debug System is "observability" for all other concepts:

• 01. Factories: Debug shows how factories process schemas
• 04. Schema Resolution: Debug tracks resolution steps
• 05. Renderer: Debug shows which renderer was chosen
• 06. Middleware: Debug displays applied middleware
• 03. Provider: Debug configured via Provider
• 02. Schema Language: Debug validates schema syntax
