From JSON to Components

System that interprets JSON schemas and transforms them into React/Vue elements — the "translator" between backend and frontend.

---

Schema Resolution is the process that transforms JSON configurations into functional interfaces:

🔧 What It Does:

Input	Process	Output	Result
JSON Schema from backend	Resolution + Validation	React/Vue Element Tree	Rendered interface
Component specs	Registry lookup	Component instances	Working components
Props and context	Middleware pipeline	Enhanced props	Correct behavior

📊 Resolution Flow:

Automatic Steps:

1. Schema Parsing: JSON → Internal structure
2. Component Lookup: x-component → React/Vue Component
3. Props Resolution: Schema properties → Component props
4. Context Injection: Form/Menu context → Component context
5. Middleware Application: Props transformation pipeline
6. Element Creation: React.createElement() / Vue h() calls

Visual Example:

{ "name": "email", "x-component": "InputText", "required": true }

↓ Resolution Process

<InputText name="email" required={true} onChange={...} />

💡 Result: Declarative schema → Imperative component.

---

🚀 Resolution Types

Different schema types require different resolution strategies:

📝 Form Schema Resolution:

Schema Property	Resolution Strategy	React/Vue Result	Example
name	Field identification	name prop	<input name="email" />
x-component	Component registry lookup	Component type	<InputText />
required	Validation rule	required prop + validation	required={true}
x-component-props	Props passthrough	Direct props	placeholder="Enter email"
x-rules	Validation configuration	Validation props	pattern="email"

🧭 Menu Schema Resolution:

Schema Property	Resolution Strategy	React/Vue Result	Example
label	Text content	children prop	<MenuItem>Dashboard</MenuItem>
url	Navigation target	href or onClick	<Link to="/dashboard" />
icon	Icon component	Icon element	<DashboardIcon />
visible	Conditional rendering	Conditional wrapper	{visible && <MenuItem />}
children	Nested menu items	Recursive resolution	<Submenu items={...} />

🎨 Component Schema Resolution:

Schema Property	Resolution Strategy	React/Vue Result	Example
x-component	Component type lookup	Component class	<Button />
x-ui	Layout/styling props	CSS/styling props	className="col-md-6"
x-component-props	Component-specific props	Props object	{ variant: "primary" }
x-reactions	Event handlers	Event props	onClick={handleClick}

---

⚙️ Resolution Engine

How the system resolves schemas internally:

🔄 Resolution Pipeline:

Raw JSON Schema
    ↓
Validate Schema (Valid JSON?)
    ↓
Resolve Component (Registry lookup)
    ↓
Map Props (Schema → Component props)
    ↓
Inject Context (Form/Menu/Global context)
    ↓
Apply Middleware (Transformations pipeline)
    ↓
Create Element (React.createElement / Vue h())
    ↓
Final React/Vue Element

🎯 Resolution Priorities:

Component Resolution Order:

1. Local components (factory props)
2. Global components (scheptaProvider)
3. Registry overrides (registerComponent calls)
4. Default components (built-in registry)

Props Resolution Order:

1. Schema-defined props (x-component-props)
2. Derived props (from schema structure)
3. Context props (form context, etc.)
4. Default props (component defaults)

Middleware Resolution Order:

1. Built-in middleware (validation, formatting)
2. Global middleware (scheptaProvider)
3. Local middleware (factory props)
4. Component middleware (component-specific)

---

📊 Resolution Strategies

Different strategies for different content types:

🎯 Expression Resolution:

Expression Type	Resolution Strategy	Example	Result
Static Values	Direct assignment	"required": true	required={true}
Segment Expressions	Context substitution	"\{\{ $segment.tenant \}\}"	"bank 1"
Association Expressions	Association lookup	"\{\{ $target.title \}\}"	"Portal Title"
JEXL Expressions	Expression evaluation	"\{\{ $segment.role === 'admin' \}\}"	true

🔧 Conditional Resolution:

Visibility Resolution:

const visible = evaluateExpression(schema.visible, context);
if (!visible) return null; // Component doesn't render

Dynamic Props Resolution:

const dynamicProps = schema['x-component-props'];
const resolvedProps = resolveDynamicValues(dynamicProps, context);

Validation Resolution:

• Rules → Props: x-rules transformed into validation properties
• Context Injection: Form context automatically injected for validation
• Error Handling: Fallbacks for invalid or malformed rules

---

💡 Related Concepts

Schema Resolution is the "processor" that connects schemas with React/Vue:

• 01. Factories: Factories use resolution to process schemas
• 02. Schema Language: Syntax interpreted by resolution
• 05. Renderer: Renderers chosen by resolution
• 06. Middleware: Pipeline executed during resolution
• 03. Provider: Context and configuration used in resolution
• 07. Debug System: Debug shows resolution steps
